--- CZ07 Slot insulation machine (air blower) ---
| Description | CZ07 Slot insulation machine (air blower) |
| Stator stack height | 10mm-120mm |
| Max. Stator O.D. | / |
| Rotor I.D.range | φ80mm-φ250mm |
| Height of edge folded | 2mm-5mm |
| Max. thickness of insulation paper | 0.15mm-0.3mm |
| Paper feeding length | 12mm-40mm |
| Tact time | 0.4-0.5 s/slot |
| Air pressure | 0.4-0.7MPa |
| Power supply | 380v/ 50Hz Three-phase four-wire |
| Power | 1.0Kw |
| Dimension(L*W*H) | 960mm *1200mm * 900mm |
| Weight | ≈350kg |
